Specifications:

X = 10,000 mm, Y = 4,000 mm, W = 800 mm, Z = 1,000 mm

Spindle speed: 10-2500 rpm

CNC: Heidenhain TNC 430

Tool magazine: 60 tools, DIN 69871

CTS 20 bar

Rotary table: S-25 CNC, W = 2000 mm

Spindle torque S1/S6 2.460/3.138

Clamping plates UD4 4000X1990

Rotary-traveling table:

    Table surface: 2500 × 3000 mm

    Max. loading capacity: 25 tons.

    Travel: 2000mm

    Continuous rotation with dual motors (master/slave configuration)

Chip conveyor

Rapid traverse 24m/min

Prepared for Andrea-type chuck and automatic milling head

CE certified, includes safety perimeter fencing
