Machining centre Hurco VMX24 Di · Hurco VMX 24Di: overview Hurco VMX 24Di: overview
Machining centre Hurco VMX24 Di · Hurco MAX5 control with WinMax software (conversational programming) Hurco MAX5 control with WinMax software (conversational programming)
Machining centre Hurco VMX24 Di · Milling on a Hurco machine Milling on a Hurco machine
Machining centre Hurco VMX24 Di · Option: Renishaw workpiece probe in the spindle Option: Renishaw workpiece probe in the spindle
Machining centre Hurco VMX24 Di · Option: CNC rotary table (4th axis) Option: CNC rotary table (4th axis)
Machining centre Hurco VMX24 Di · Option: production package (paper band filter and 20 bar through-tool coolant) Option: production package (paper band filter and 20 bar through-tool coolant)
Machining centre Hurco VMX24 Di · ProCobots automation: part loading with a collaborative robot ProCobots automation: part loading with a collaborative robot
1 / 11

Hurco

Machining centre Hurco VMX24 Di

High-performance VMX vertical with a direct-drive SK40 spindle at 15,000 rpm, travels of 610 × 508 × 610 mm and WinMax conversational control.

Ref. HURCO VMX24Di

Travels X/Y/Z
610 · 508 · 610 mm
Spindle
15,000 rpm SK40 · 57 Nm
Table · max. workpiece
760 × 510 mm · 1,500 kg
Tools
30
Weight
4,748 kg
CNC control
Hurco WinMax · MAX5
Call +34 966 662 296

We reply within 24 working hours.

Technical data

Select a section to see the details:

SpeedTaperPower (100 % / 40 % DC)Torque (100 % / 40 % DC)Availability
15,000 rpm (direct drive) Most common SK409 kW57 NmStandard
StandardWorktable Size760 × 510 mm; 5 T-slots of 18 mm (H8), 100 mm pitchMax. load1,500 kg
CNC rotary table for 4th / 5th axis (MR, GT or TT)
OptionCNC rotary table for 4th / 5th axis (MR, GT or TT) Sizeplates Ø 128 to 320 mm
Automatic tool changer (ATC)30 tools
Max. toolMax. Ø 80 mm · max. length 300 mm · max. weight 7 kg
Rapid traverse X/Y/Z (m/min)45 / 45 / 40
Axis thrust X/Y/Z (kN)10,7 / 10,7 / 16,8
Spindle nose to table distance152 - 762 mm
CNC controlHurco MAX5 with WinMax: conversational programming at the machine and ISO (NC) code
Space required (L × W × H, doors open, including control and conveyor)3,930 × 4,046 × 2,994 mm
Coolant tank367 l
Swarf evacuation (standard)scraper conveyor
Travels X/Y/Z610x508x610
X-axis travel610
Y-axis travel508
Z-axis travel610
Spindle to table surface distance152-762
T-slots (W x pitch x no.)5x18
Worktable (L x W)760x510
Spindle speed15.000
Main motor9
Rated motor torque57
Cutting feed X/Y/Z axes38/ 38/ 32
Pull studSK40
No. of tools30
Max. tool diameter80
Max. tool length300
Max. tool weight7
Machine weight5000
Machine footprint (L x W x H)2.931x2.841x2.994

Data from the manufacturer's catalogue; the final configuration is confirmed in the quotation.

Automation options

Ready to be automated from day one or whenever you need it: more spindle hours without an operator and a lower cost per part.

ProCobots: loading and unloading with a collaborative robotRobotProCobots: loading and unloading with a collaborative robot

Feeds the machine without an operator to extend shifts and run unattended. The robot is programmed from the MAX5 control itself (Automation Job Manager), with no need to program on the robot.

✓ ProFeeder Cart / Tray with UR10e or EasyDesk 20 | 30 with UR20 / UR30 · Schunk gripper for parts up to 15 kg

Hurco also offers an open interface for integrating third-party robots and automation systems (AMF, Erowa, Lang Technik, Robojob, Universal Robots…). Please confirm the configuration for this model with Ferrotall.
